Technical specifications:

·         Using by touch screen display

·         Measures in opening and closing directions

·         Measuring range: 00.00 to 99.00 Kgf.cm

·         Sample range: 30 - 110 mm in diameter / 80 - 370 mm in height (other range by order)

·         2 measuring cycles (Opening or Closing, Removal +Breaking)

·         Units: Kgf.cm / N.m / Inch.lbs / N.cm

·         Measure head rotating speed adjustable (0.3 - 10.0 rpm)

·         Accuracy:  0.5 % of full scale

·         30 products memorization

·         Up to 8 thresholds (limits) option (according to cycle)

·         10 operators memorization

·         Configuration by protected password (administrator)

·         Operation pressure monitoring, auto warning for insufficient operation pressure

·         Memorization up to 990 measures (transferable)

·         Dynamic display: statistics / hour / date

·         Display: product name / operator / batch N° / Sample N°

·         1 RS232 & 1 mini-printer interface

·         Language: English

·         Delivered with calibration certificate COFRAC

·         5 - 8 bar air network

·         AC 110 - 240 V 50/60 Hz

Automated part:

·         One key start, just press the start button to carry out the test process

·         Automatic zero before restarting cycle

·         Height of measure head auto adjust according to the samples

·         Easy-fast selector for cycles

·         Settable speed for screwing and unscrewing operations

·         Pneumatic cap clamping chuck

Mechanical specifications:

·         Stainless steel Frame

·         Choice of jaw, or bottle neck clamp

·         Dimensions: 385 (L) x 600 (W) x 1050 (H) mm

·         Weight: 56 kg

Optional parts:

·         Mini printer

·         QUALITORQ Software

·         Calibration pack

·         Dynamometric system
