Technical specifications:

·         Using by touch screen display

·         Measures in opening and closing directions

·         Measuring range: 00.00 to 99.00 Kgf.cm

·         Sample range: 50 - 90 mm in diameter / 110 - 350 mm in height

·         7 measuring cycles: Torque closing / Reach position / Release + break /

Release + break + over screw / Non-destructive test / Cork extraction test / Removal + breaking + strip torque + close

·         Units: Kgf.cm / N.m / Inch.lbs / N.cm

·         Rotating angle & speed adjustable under certain cycle

·         Accuracy:  0.5 % of full scale

·         30 products memorization

·         Thresholds (limits) settings for each product

·         10 operators memorization

·         Memorization up to 1000 measures (transferable to mini-printer)

·         1 RS232 output and 1 printer output (software & printer)

·         Language: English, French, Spanish, Chinese, others on request

·         Delivered with calibration certificate COFRAC

·         AC 220V

Automated part:

·         Safety door

·         Automatic zero before restarting cycle

·         Settable height of column for all samples

·         Easy-fast selector for cycles

·         Settable speed for opening and closing operations

·         Customized cycles

·         Special pneumatic chuck available

·         Special multi format system for both bottle and preforms

·         Dynamometric system

Mechanical specifications:

·         Stainless steel Frame

·         Choice of measuring chucks: Beverage / Cosmetic / Pharmacy

·         Dimensions: 610 (L) x 560 (W) x 1140 (H) mm

·         Weight: 94 kg

Optional parts:

·         Mini printer

·         QUALITORQ Software FDA - CFR 21-11

·         Customized display & cycles

·         Calibration pack

·         Dynamometric system

·         Starwheel system
